shuttle

Inference and serving for twill.
Written in twill.

---

It runs

shuttle is written in twill, in .tw files, using mode systems. That subset did not exist when this library was written, so for a long time none of the code here executed and this section said so. twill 1.6 is the release that closed it: the 6 test suites under tests/ pass, the example loads a published model and answers with it, and CI runs both against a released twill on every push rather than gating on the prose in this file.

You need twill 1.7.0 or newer. Get one:

curl -fsSL -o twill https://github.com/twill-lang/twill/releases/download/v1.7.1/twill-v1.7.1-linux-amd64
chmod +x twill

The asset name is twill-v1.7.1-<os>-<arch>: linux-amd64, linux-arm64, darwin-amd64, darwin-arm64, windows-amd64.exe.

The suite needs a checkout of selvedge beside this one, because src/model.tw imports its archive reader by path. Then, from the repository root:

$ twill test tests
ok    tests/batcher_test.tw
ok    tests/model_test.tw
ok    tests/predict_test.tw
ok    tests/quant_test.tw
ok    tests/score_test.tw
ok    tests/signature_test.tw

6 file(s): 6 passed, 0 failed

And the example. This is the run with the model selvedge publishes already in place; see the pipeline below for how it gets there:

$ twill run examples/serve.tw
[email protected] (1af561e0982a) f64, input [_, 4] -> [_, 3] logits
warmed 2 pass(es) at batch sizes 1 32
class 0 with 0.999148
blobs: shape error: the input axis 0 is 2 but the model expects 4 ([2] against [4])
batches 3  rows 12  mean 4  configured max_batch 32 max_hold 4  refused 0
scoring 192/192 (100%)
scored 192 rows
bf16: over 72 rows: mean |diff| 0.010978, max |diff| 0.047055, argmax disagreements 0
f16:  over 72 rows: mean |diff| 0.001167, max |diff| 0.004079, argmax disagreements 0
int8: over 72 rows: mean |diff| 0.028892, max |diff| 0.160998, argmax disagreements 0
stored today:   1048 bytes
int8 realised:  195 bytes

The shape error on the fourth line is deliberate: the example sends a two-element request to a four-feature model to show what the refusal looks like.

Without examples/models/blobs-1.2.0.slv the example still runs. It falls back to md.from_params over an untrained tree and a signature declared in the file, which is the weaker of the two load paths and is exactly the one this README argues against, so it says so on the way past.

The pipeline

Three repositories, one file handed along each edge. Checked out side by side:

cd loom     && twill run examples/classifier.tw
cp loom/examples/runs/blobs.params selvedge/examples/runs/blobs.params
cd selvedge && twill run examples/publish.tw
cp selvedge/examples/models/blobs-1.2.0.slv shuttle/examples/models/blobs-1.2.0.slv
cd shuttle  && twill run examples/serve.tw

docs/needs.md is still worth reading -- it is the list of what this library asked the language for, and it now records which of those arrived and which are still open.

What shuttle is

The layer between a trained model and the thing that uses it. loom trains, selvedge ships, shuttle answers.

Every row below names the test or the example that runs it. A row that names nothing is a row that claims nothing.

Piece	State
Load a selvedge archive, integrity verified before the weights are trusted	runs. tests/model_test.tw writes an archive and loads it back; the example loads the published one
Single, batched and streaming prediction	runs. tests/predict_test.tw, and the example does all three
Input validation against the model's declared shapes, with twill's kind of message	runs. tests/signature_test.tw asserts the message text and not only that it failed
Dynamic batching with the latency-throughput trade as two required numbers	runs. tests/batcher_test.tw, and the example drives 12 arrivals through it
Warmup, with a written-out list of what it does and does not cover	the example calls it and it reports the shapes it warmed. No test under tests/
int8, float16 and bfloat16 with min-max and percentile calibration	runs. tests/quant_test.tw, and the example compares all three on held-out rows
Batch scoring over a dataset, chunked, with progress	runs. tests/score_test.tw, and the example scores 192 rows
Accuracy evaluation over a labelled dataset	runs. sc.evaluate, covered by tests/score_test.tw. No example uses it
A quantisation size win	numerics real; bytes gated on twill NEEDS-111. See below
A progress time estimate	not wired. twill 1.7 has mono_ns; shuttle does not call it. See below
A network server, a port, a socket, a request thread	not possible, and not planned
Anything running end to end	runs. twill run examples/serve.tw, output above

The forward pass stays yours

shuttle does not own your update rule and it does not own your forward pass either. Every entry point takes the forward function as an argument. The thing that makes a model yours is its forward pass, and a serving library that hid it inside itself would be a library you had to fork to serve anything it did not anticipate.

What shuttle owns is everything around the call: the signature check, the batching, the warmup, the quantised parameters, the chunking, and the counting.

mode systems

import "twill_modules/shuttle/src/model.tw" as md
import "twill_modules/shuttle/src/predict.tw" as pr
import "twill_modules/shuttle/src/batcher.tw" as bat
import "twill_modules/shuttle/src/warmup.tw" as wu

fn forward(p: Tree, x: Tensor) -> Tensor {
  let h = relu(x @ transpose(p.w1) + p.b1)
  h @ transpose(p.w2) + p.b2
}

# The signature comes out of the archive, so the shape check is against what the
# model was published with rather than what this file believes.
let loaded = md.from_archive("models/blobs-1.2.0.slv")
let model = loaded.model

# Both numbers are required. Neither has a default. See below.
let cfg = bat.config(32, 4)
wu.warm(model, wu.sizes_for(cfg.max_batch), forward)

let one = pr.predict(model, [1.2, 0.4, -0.8, 2.1], forward)

examples/serve.tw is a complete program: load, warm, one request, a batched stream of requests, a scored file, and a measured comparison against int8.

Shape errors, at the boundary

twill's best property is that a shape mistake is an error you see before the program runs. Serving gives that up: the input arrives at runtime, from a file or a caller, and the checker never saw it. A served model is exactly the place twill's guarantee does not reach.

So shuttle rebuilds it by hand, at the entry point, in the same vocabulary:

toy: shape error: the input axis 1 is 6 but the model expects 4 ([8, 6] against [_, 4])

rather than what happens without it, which is a matmul failing four calls deep with the shapes of two intermediate tensors nobody named. The axis is named, not just the shapes: for a rank-4 image tensor, "expected [_, 1, 28, 28] and got [16, 1, 28, 32]" makes a reader diff two lists, and "axis 3 is 32 and the model expects 28" does not.

Validation happens once, at the entry point, and nothing downstream re-checks. A check inside a loop is a check someone removes for speed.

Three cases get their own message because they are the mistakes people actually make. Passing a batch to the single-input path is diagnosed as that, and names predict_batch. An empty batch is refused rather than answered with an empty output, because a service that silently returns nothing for an empty request is a service whose caller has a bug it cannot see. And a forward function that returns a different number of rows than it was given is caught and blamed on the model rather than on the request.

The batching knob is two numbers and neither has a default

Batching n requests into one forward pass is faster per request and slower for the first request in the batch. That is not a tuning detail. It is the deciding question about a serving system, its answer is different for a fraud check and for an overnight job, and neither answer is knowable from inside a library.

So shuttle has no heuristic. It has two numbers, both required:

Knob	What it buys	What it costs
max_batch	throughput per row, wider matmuls, fixed cost paid once	memory, proportional to the batch
max_hold	throughput, by letting a batch fill	latency, for every request that waits

max_hold = 0 means never wait: every request runs alone, latency as low as it goes, throughput as bad as it gets. max_hold = max_batch - 1 means always fill the batch. Everything useful is in between and where in between is your decision.

validate refuses the configurations that do nothing, rather than accepting them quietly:

max_hold 8 is not below max_batch 8, so the hold never expires and only
max_batch has any effect

And report gives you the realised trade next to the configured one, because a configured max_batch of 64 against a realised mean of 3 means the knobs are not doing anything and nobody would otherwise notice.

The hold counts arrivals, not milliseconds

Every real dynamic batcher holds a batch for a duration. shuttle's does not: max_hold counts arrivals instead.

twill has a clock. mono_ns() and clock_now_ms() landed in 1.7 and this README used to say they did not exist. src/batcher.tw calls neither, so the hold is still counted in arrivals and the paragraph below is still what the knob does. What changed is whose work it is: a duration-bounded hold is now a shuttle change rather than a language request. It is not a small one. A hold that expires on time needs something to notice the expiry, and with no concurrency nothing runs between submit calls, so the deadline can only be checked when the next request arrives, which is the case the arrivals count already covers. The honest version needs a caller-driven tick, and that is a design decision this library has not made. docs/needs.md entry 3.

This is a worse knob and it is the honest one. Counting arrivals bounds the wait in requests and not in time, so under a trickle of traffic a request can wait indefinitely for the next one and the tail latency is unbounded.

shuttle's hold is safe for a bounded workload and unsafe for an open-ended stream of requests. Batch scoring a file is bounded. Anything driven by arrivals you do not control is not. flush runs whatever is queued regardless, and calling it is the caller's job because only the caller knows its input is exhausted. docs/needs.md entry 3 is the clock that fixes this, and it is the first entry for a reason.

There is also no concurrency, so nothing arrives while something else is running. This is a batcher in the sense of accumulating work and cutting it into passes of a chosen size, which is the part that matters for throughput. It does not overlap waiting with computing, because there is nothing to overlap with.

What warmup covers, and what it does not

Warmup runs the model on synthetic input, at the shapes real requests will have, before the service starts answering. A warmup with an unstated scope is a ritual, so here is the scope.

Covered. Lazy work inside your forward function, which is the largest real item and is entirely in your code: a constant, a mask, a positional encoding or a lookup table built on first use. Dequantisation, if the model is quantised, which for int8 is the largest single item on this list. Faulting the parameter pages in after loading a large archive. And every distinct batch shape you name, which is why it takes a list: a model warmed at batch 1 and asked for batch 64 pays the batch-64 costs on the batch-64 request.

Not covered. JIT compilation, kernel selection and autotuning, because twill has none of them. If you have read about warmup in another framework, most of what it bought there does not exist here to buy. Nothing on a GPU, because there is no GPU backend. Data-dependent branches, because synthetic input warms the wrong path for a model whose cost depends on its values rather than its shapes: warm_with takes real rows for exactly that. And anything after the first request.

The honest summary. For a dense float model in twill today, warmup buys the lazy work in your own forward function and the page faults. Real, and not large. For an int8 model it buys the dequantisation, which is large. shuttle reports the shapes it warmed and refuses to claim a saving. It could measure one now: twill 1.7 has mono_ns, and src/warmup.tw does not call it. That is a real gap and it is shuttle's, not twill's.

Synthetic input is drawn from the standard normal, not zeros. A relu on a zero input is uniformly on the flat side and every comparison against zero takes one branch, which warms half the code.

Quantisation, and what it actually costs

Read this before using src/quant.tw.

twill now has narrow dtypes. A tensor carries a dtype, x.to(f16) and x.to(i8) are correctly-rounded casts, and the conversions match the formats exactly, subnormals and overflow included. So the numerics shuttle applies are real today: quantising rounds the way an int8, f16 or bf16 deployment would, and you can measure the accuracy cost on your data before committing to it.

The bytes do not drop yet, and that is a gate rather than a fiction. A narrow tensor holds narrow values but still occupies eight-byte slots until two things land upstream: the packed byte buffer that backs it (twill NEEDS-111, four native primitives) and a narrow on-disk encoding (a selvedge archive format bump). When they do, the ratios below are real and no code in src/quant.tw changes, because the rounding was always the hard half. Until then, stored_bytes with realised: false reports the true current footprint and with true the footprint after the gate clears; the default is never the aspiration.

Every number below is labelled with where it comes from. Nothing in the table is a benchmark result: no timing has been run, and the ratios are arithmetic. The accuracy figures further down are measured, on one small model, and are labelled as that rather than as a general result.

Quantising does not make the file smaller today. twill stores every float as an f64 whatever dtype it carries, so rounding a weight to bfloat16 changes the value and not the eight bytes it sits in. The ratios below are what the file becomes once the packed storage lands.

Scheme	Bytes/param	vs f64	Max representation error	Task accuracy
float64	8	1.00x	0	baseline
bfloat16	2	4.00x	3.9e-3 relative, DERIVED	UNMEASURED
float16	2	4.00x	4.88e-4 relative, DERIVED	UNMEASURED
int8	1 + scales	~7.9x	half a step, DERIVED	UNMEASURED

• GATED, not PROJECTED. The ratios are real once the two upstream pieces named above land; the tensor already rounds to the dtype, so nothing but the storage stands between here and the number. stored_bytes(m, scheme, tensors, realised) returns the current footprint or the gated one by its last argument.
• DERIVED, bfloat16. Seven stored significand bits round a value to within 2^-8, about 3.9e-3 relative. It keeps f32's eight exponent bits, so its range is f32's and it does not overflow a value f32 could hold: no clamp, no loss scaling. This is the safer 16-bit default.
• DERIVED, float16. An 11-bit significand rounds a value to within 2^-11 of itself, which is 4.88e-4 relative, finer than bf16. Its range is only about 6e-5 to 65504, and a weight outside it flushes to zero or to infinity. shuttle no longer hides that behind a clamp, because the cast is real: an f16 overflow is a genuine hazard and the reason to prefer bf16 unless the finer step is measured to pay.
• DERIVED, int8. Over a calibrated range the step is (hi - lo) / 255 and rounding puts each weight within half a step. The 256 levels are centred to a real signed i8 tensor, one byte per code. The ~7.9x rather than 8x is the per-tensor scale and zero point: n / (n/8 + 2) bytes, which is 7.94x at n = 1024 and 7.999x at n = 1e6.
• UNMEASURED. What happens to your model's accuracy. It depends on the depth of the network, on whether the errors accumulate or cancel, and on how close your decision boundary is. shuttle will not guess, and compare runs both models over your held-out data in one call so you do not have to. It reports the shape below, and the values are yours rather than ours:

f16:  over N rows: mean |diff| ..., max |diff| ..., argmax disagreements ...
int8: over N rows: mean |diff| ..., max |diff| ..., argmax disagreements ...

examples/serve.tw fills that shape in on the model loom trains and selvedge publishes, over 72 held-out rows:

bf16: over 72 rows: mean |diff| 0.010978, max |diff| 0.047055, argmax disagreements 0
f16:  over 72 rows: mean |diff| 0.001167, max |diff| 0.004079, argmax disagreements 0
int8: over 72 rows: mean |diff| 0.028892, max |diff| 0.160998, argmax disagreements 0

Those are MEASURED, on one four-tensor MLP over three well separated blobs, and they are not a result about quantisation. A model with a decision boundary anywhere near its data would move rows, and this one has none near it: zero disagreements over 72 rows says the blobs are separable, not that int8 is free. Run it on your own held-out data, which is what compare is for.

The argmax disagreement count is the one that decides whether a quantisation is acceptable, and it is not derivable from the weight error: two models can differ by 1e-6 everywhere and disagree on 3% of rows near the boundary.

Calibration is the whole decision for int8. minmax loses nothing at the extremes and everything in the middle if there is one outlier weight: a single weight at 100 with the rest inside [-1, 1] gives a step of 0.4, and every real weight rounds to one of five values. percentile(0.999) clips the tail and gets a step a hundred times finer. It is almost always the better trade and it is not the default, because clipping a weight should be a decision someone made.

Activation calibration is not implemented. Most of the accuracy loss in a real int8 deployment comes from activations rather than weights, and calibrating them means watching the inside of the forward pass, which is deliberately the caller's. docs/needs.md entry 8 records that as a decision rather than an omission.

Batch scoring

The offline half. No requests arrive, the input is a file, and the failure that hurts is running out of memory at 80% through a four-hour job.

let scored = sc.score_csv(model, "batch.csv", 512,
  sc.progress(5000, "scoring", 0), forward)

scoring 5000/120000 (4%)
scoring 10000/120000 (8%)

Chunked, so peak memory is one chunk's activations rather than the file's: predict_batch on a million rows materialises a million rows of every intermediate in the forward pass. score_to holds nothing at all, handing each chunk to a sink as it is produced, and a sink that returns an error stops the job, which is how a caller cancels.

The chunk size does not change the answer. It changes peak memory and nothing else, and there is a test that says so.

The input is not streamed. read_csv reads the whole file, because twill has no streaming reader, so a file larger than memory cannot be scored. The chunking bounds the activations and not the input. docs/needs.md entry 5.

No time estimate. shuttle prints a percentage, and the useful part of a progress report on a four-hour job is the time remaining. twill 1.7 has mono_ns and src/score.tw does not call it, so this is shuttle's omission and no longer a language limit. docs/needs.md entry 3.

Stated limits

Collected, so none of them has to be discovered.

• No network server, no socket, no port, no request thread. twill has none of the primitives and this is not planned.
• No concurrency. The batcher accumulates and cuts; it does not overlap.
• Nothing here reads a clock. The batching hold counts arrivals, warmup reports no saving, and progress has no estimate. twill 1.7 has mono_ns and clock_now_ms; no file in src/ calls either, so all three of those are shuttle's work and not the language's.
• Quantisation rounds for real but does not shrink the file yet. The numerics are exact; the bytes drop once twill NEEDS-111 and a narrow archive encoding land. Until then it measures what shrinking will cost.
• The input to score_csv is read whole. Only the activations are chunked.
• Lit progress lines, but no stateful bar. The progress line is coloured from twill's palette. Nothing is vendored: std/term/caps, std/term/ansi and std/term/theme are ordinary std/ modules and src/score.tw imports them directly. It drops to plain text when piped. There is no std/cli, so there is no rate-and-ETA bar to adopt; docs/needs.md entry 11.
• flush is the caller's job. Forget it and the last partial batch is never run.

Install

mode systems works. spool does not vendor shuttle for you yet, so until it does the way in is a clone with selvedge beside it, or:

spool add shuttle https://github.com/twill-lang/shuttle

spool vendors into twill_modules/, and twill's import is a path, which is why the import lines above are the long ones. A path in twill, whether it is an import or an argument to read_csv or save, resolves against the directory of the file that contains it, not against the working directory. So src/model.tw reaches selvedge as ../../selvedge/src/archive.tw, and twill run examples/serve.tw reads and writes under examples/ whatever directory you invoke it from. That is twill's rule rather than shuttle's; see spool's README.

Repository layout

src/signature.tw      shapes, and the errors twill would have given you
src/model.tw          a loaded model, from an archive or from bare parameters
src/predict.tw        single, batched and streaming prediction
src/batcher.tw        the latency-throughput trade, as two required numbers
src/warmup.tw         what it covers and what it does not
src/quant.tw          int8, float16 and bfloat16, calibration, and an honest table
src/score.tw          batch scoring, progress, and accuracy
tests/                tests, named as sentences
examples/serve.tw     load, warm, predict, batch, score, compare
docs/needs.md         what the language still has to provide

Dependencies

twill, and selvedge for reading model archives. Nothing else, and no Go.

selvedge is a real dependency rather than a convenience: from_archive gets the model's signature out of the file, so the shape check is against what the model was published with. from_params takes a bare saved tree and a signature you declare, which works and turns the signature into a claim. A declared signature that is wrong produces a check that passes and a forward pass that fails, which is worse than no check, because it moved the error later without removing it.

Contributing

The most useful contribution right now is not code. It is a correction to docs/needs.md: a feature listed there that the language already has, a workaround that is worse than described, or a missing entry found by reading the source. After that, the quantisation table is the part most worth arguing with, because every number in it is labelled with where it came from and a wrong label is a bug.

License

MIT. See LICENSE.
